ATH W62 LCD 2D
ATH W64 P
ATH W64 P Plus
Product Innovation Q4 / 25
€5,037.82
plus assembly and freight
€5,995.01
- Static program: Enables balancing in static mode for precise weight distribution
- Dynamic program: Enables optimal balancing at different speeds
- Optimization program: Program for fine-tuning and optimizing the balancing process
- Aluminum balancing programs: Four special programs for aluminum rims to improve balancing quality
- Rear spoke weight positioning: Enables the exact distribution of weights behind the spokes
- Sonar technology: Contactless scanning of the rim width
- Extended clamping shaft: Additional clamping shaft for the use of additional clamping devices
- Automatic positioning: Automatically positions the wheel for attaching the weights
- Tool holder: Practical storage of tools directly on the wheel guard
- Optional motorcycle function: Additional function for balancing motorcycle wheels
- including wheel jack ATH RRH1107
More Information
| Center hole diameter rim |
45 – 130 mm |
| Measuring time car | truck |
8 s |
| Measurement tolerance |
+/- 1g |
| Measuring speed |
200 U/min |
| Rim width |
1,5" - 20" |
| Rim diameter |
10“ – 24“ |
| Max. wheel diameter |
900 mm |
| Wheel weight max. |
65 kg |
| Compressed air connection |
8 bar |
| Monitor |
22“ LED |
| Driving power |
0,20 kW |
| Power supply voltage |
230V / C16A |
Due to data compliance rules, we require your consent for
marketing cookies to display this content.
We can also advise you by phone +49 (0) 9666 18801-00
Download Product-flyer
