ATH W64 P Plus

ATH W64 P Plus

ATH W64

ATH W64

ATH W64 P

€3,357.14 plus assembly and freight
€3,995.00
Availability: In stock
item number
150055
Share on
  • Pneumatic shaft: 40 mm clamping shaft for quick and secure wheel clamping
  • Sonar technology: Non-contact rim width detection
  • Automatic positioning: Automatically positions the wheel for weight attachment
  • Extended clamping shaft: Additional clamping shaft for use with other clamping devices
  • Laser indicator: Enables precise placement of the clamping weights at the 6 o'clock position
  • Static/Dynamic program: Enables optimal balancing at different speeds
  • Alu balancing programs: Special programs for aluminum rims to improve balancing quality
  • Split rear spoke weight positioning: Enables precise weight distribution behind the spokes
  • Optimization program: Program for fine-tuning and optimizing the balancing process
  • Optional motorcycle function: Additional function for balancing motorcycle wheels
More Information
Center hole diameter rim 45 – 130 mm
Measuring time car | truck 8 s
Measurement tolerance +/- 1g
Measuring speed 200 U/min
Rim width 1,5" - 20"
Rim diameter 10“ – 24“
Max. wheel diameter 900 mm
Wheel weight max. 65 kg
Compressed air connection 6 bar
Monitor 22“ LCD
Driving power 0,20 kW
Power supply voltage 230V / C16A
Due to data compliance rules, we require your consent for marketing cookies to display this content.

We can also advise you by phone +49 (0) 9666 18801-00

Download Product-flyer Download Product-flyer
