ATH W82 Touch 3D Plus

ATH W82 Touch 3D Plus

ATH W62 LCD 2D

ATH W62 LCD 2D

ATH W62 LCD 3D

€3,189.08 plus assembly and freight
€3,795.01
Availability: In stock
item number
150035
Share on
  • Automatic distance, rim diameter and rim width (3D function) measurement
  • Operation via ergonomically arranged front control panel, large shelf with numerous compartments
  • Digital and optical position display of the weights via 19" LCD monitor and duo laser (LPS)
  • Static / dynamic, ALU programs, ALU weight optimization and back spoke placement
  • Quick-release nut clamping with 40 mm shaft diameter, easy attachment of the weights via pedal-operated parking brake and measuring tool, integrated interior wheel lighting
  • Wheel protection with automatic start-stop function
  • Precise work thanks to the latest microprocessor control
  • Ideally suited for car wheels, with optional accessories also for motorcycle and light truck wheels
More Information
Center hole diameter rim 45 – 130 mm
Measurement tolerance ± 1 g
Measuring time 7 s
Measuring speed 180 U/min
Rim width 1,5 – 20 "
Rim diameter 12 – 24 "
Max. wheel diameter 900 mm
Wheel weight max. 65 kg
Driving power 0,25 kW
Power supply voltage 230V / C16A
