ATH-Flex Lift 30Z

ATH-Flex Lift 30Z

ATH-Flex Lift 30

€2,895.00 plus assembly and freight
€3,445.05
Availability: In stock
item number
680008
  • High-quality and robust short-stroke lift with hydraulic drive, almost maintenance-free
  • Powerful hydraulic unit (230V / C16A)
  • Very low drive-over height of only approx. 105 mm
  • No electrical limit switches, protective hose over the hydraulic lines
  • Mechanical synchronization through cross connection and double hydraulic lines
  • Full lifting power from the lowest point
  • Emergency lowering system for lowering in the event of a power failure
  • Ideally suited for paint and body shops, repairs, brake and tire services
More Information
Color anthracite-grey
Rated load capacity 3 t
Lifting height max. 960 mm
Drive-on-height 105 mm
Total platform length 1.450 – 2.040 mm
Total platform width 530 mm
Driving power 2,2 kW
Lifting/Lowering time ca. 20 s
Power supply voltage 230V / C16A
Concrete strength min. C20/25 Dicke: 200 mm
