ATH RG5.5-4 WB

ATH RG5.5-4 WB

ATH RG8.5-4 WB

ATH RG8.5-4 WB

ATH RG5.5-6 WB

€31,928.57 plus assembly and freight
€37,995.00
Availability: In stock
item number
710037
Share on
  • Electro-hydraulic wheel gripper system with battery operation and wireless control
  • Control unit including unit cover on each column for flexible use
  • Master unit controls all operating information on each column and an extension up to 16 columns
  • Integrated quick charger per column, enables charging during use.
  • Mobile kit and forklift attachment on the columns enable a faster change of position
  • Safety Control: hydraulic shut-off valve, electronic synchronization monitoring and electromagnetic safety locks
  • Safety Lock: ability to lock the load on to the safety mechanism
  • Multifunctional mounting via variable wheel fork with individual setting options
More Information
Rated load capacity 5,5 t
Lifting height max. 1.750 mm
Overall height 2.750 mm
Column width 1.110mm
Driving power 2,2 kW
Lifting/Lowering time 80s / 70s
Power supply voltage DC 24V
Column communication kabellos
Concrete strength min. C20/25 Dicke: 200 mm
Due to data compliance rules, we require your consent for marketing cookies to display this content.
Due to data compliance rules, we require your consent for marketing cookies to display this content.
Due to data compliance rules, we require your consent for marketing cookies to display this content.

Product Catalog

Due to data compliance rules, we require your consent for marketing cookies to display this content.
Due to data compliance rules, we require your consent for marketing cookies to display this content.

We can also advise you by phone +49 (0) 9666 18801-00

Download Product-flyer Download Product-flyer
