ATH Four Lift 55AP
ATH Four Lift 64AP
ATH Four Lift 64P
€11,088.24
plus assembly and freight
€13,195.01
- Electro-hydraulic 4-post lift with quick lift unit and load-dependent lowering function
- Central operating unit, including unit cover
- ATH Four Lift 64AP: Level running rail with integrated wheel alignment kit
- ATH Four Lift 64P: level runway, optional wheel alignment kit
- Precisely levelable notch and rail system
- Safety Control: Electropneumatic safety locks that automatically unlock with lifting and lowering
- Safety Lock: ability to lock the load on to the safety mechanism
- Multifunctional mounting via continuously adjustable rails
- Perfect platform protection made of special polymer and double powder coating
More Information
Rated load capacity |
6.400 kg |
Lifting height max. |
1.850 mm |
Drive-on-height |
235 mm |
Total platform length |
5.310 mm |
Total platform width |
512 mm |
Driving power |
4,0 kW |
Lifting/Lowering time |
ca. 48 s |
Power supply voltage |
3x 400V / C16A |
Concrete strength |
min. C20/25 7.400 x 3.900 x 200 mm |
