ATH-Four Lift 55HAP
ATH-Four Lift 55HP
€9,795.00
plus assembly and freight
€11,656.05
- Electro-hydraulic 4-post lift with quick lift unit and load-dependent lowering function
- Central operating unit, including unit cover
- Level running rail with integrated wheel-free jack (load capacity 3.5t) optional wheel alignment kit
- Precisely levelable notch and rail system
- Safety Control: Electropneumatic safety locks that automatically unlock with lifting and lowering
- Safety Lock: ability to lock the load on to the safety mechanism
- Multifunctional mounting via continuously adjustable rails
- Perfect platform protection made of special polymer and double powder coating
More Information
Color |
anthracite-grey / black |
Rated load capacity |
5,5 t |
Lifting height max. |
1.960 mm |
Drive-on-height |
210 mm |
Total platform length |
5.600 mm |
Total platform width |
650 mm |
Driving power |
4 kW |
Lifting/Lowering time |
ca. 45 s |
Power supply voltage |
3x 400V / C16A |
Concrete strength |
min. C20/25 7.400 x 3.900 x 200 mm |
We can also advise you by phone +49 (0) 9666 18801-00
Download Product-flyer
